Holley Keith Dorton Series Intake - Chevy Small Block V8
SKU
HTPD-300-110
List price
$635.95
Price
$564.95
Description
Keith Dorton Series Intake Manifold 1957-1986 262ci-400ci, 1987-later with Aluminum Heads
Features
- Power band: 4500-8500 RPM
- Isolated Water cross-over
- Square Bore Carburetor Mounting Flange
- Single Plane with Isolated Plenum
- Port Size: 2.00” height 1.20" width
- Height: Front 6.13", Rear 6.13"
Specs
Brand
HOLLEY
Category
Engine Intake Manifold
Specs
Brand: Holley
Color: Natural
Engine: Chevrolet Small Block Gen I
Finish: Satin
Warning: California Proposition 65
Category: Engine
EGR Port: No
Material: Aluminum
Warranty: Manufacturer's Limited 90 Day Warranty
part type: Engine Intake Manifold
Grade Type: Performance
Rear Height: 6.13 inch
Construction: Cast
Flange Style: 4150 Square Bore
Front Height: 6.13 inch
Product Type: Intake Manifold
Sub Category: Cylinder Block Components
Emission Code: 4
Manifold Type: High Rise
Plenum Finish: Natural
RPM Power Band: 4500-8500
Fuel System Type: Carb
Carburetor Flange: Square/4150
Removable Runners: No
Removable Top/Lid: No
Rear Maximum Height: 6.13
Front Maximum Height: 6.13
Fuel Rail(s) Included: No
Throttle Body Included: No
Fuel Injectors Included: No
Gasket Or Seal Included: No
Nitrous Bung(s) Included: No
Basic Operating RPM Range: 4500-8500
Carburetor Studs Included: No
Single Or Dual Plane Type: Single Plane
Intake Port Gasket(s) Included: No
