Holley Fuel Cell EFI Pump Module Assembly
SKU
HTPD-12-146
List price
$779.94
Price
$649.95
Description
12-Bolt Flange 450 LPH Drop-In EFI
Features
- Update your fuel cell to EFI the easy way!
- Designed to drop right into your existing 12 bolt flange fuel cell
- Billet top flange housing includes an 8AN inlet and 10AN outlet port and a fuel filler cap
- Modules are available with 255 or 450 LPH fuel pumps in single pump configurations
- The pump depth is fully adjustable for fitment in the most popular cell sizes 7.5”-12” deep.
- Supports up to 875 EFI or 1100 Carb HP (@ 60 PSI at 13.5 Volts / 16.9 AMP Draw)
Specs
Brand
HOLLEY
Category
Fuel Pump Module Assembly
Specs
Brand: Holley
Height: Adjustable
Max PSI: 87
Voltage: 12
Warning: California Proposition 65
Category: Air and Fuel Delivery
Warranty: Manufacturer's Limited 90 Day Warranty
Fuel Type: E85
Pump Type: Electric
Grade Type: Performance
Inlet Size: 8 AN
Inlet Type: 8 AN ORB
Application: Universal
Outlet Size: 10 AN
Outlet Type: 10 AN ORB
Flange Style: 12 Bolt
Product Type: Fuel Pump
Emission Code: 5
Free Flow GPH: 118
Free Flow LPH: 450
Wire Quantity: 2
Inlet Quantity: One
Negative Ground: Yes
Outlet Quantity: One
Housing Material: Aluminum
Maximum Pressure: 60
Lock Ring Included: Yes
Regulator Included: No
Average Flow Rating: 450
In Tank or External: In Tank
Single Or Dual Pump: Single
Average Current Draw: 16.9
Fuel Filter Included: Yes
Wire Harness Included: Yes
Gasket Or Seal Included: Yes
Gasket Or Seal Material: Cork
Universal Or Specific Fit: Universal
Fuel Sending Unit Included: No
Mounting Hardware Included: Yes
Internal Or External Strainer: External
Fuel Tank Pressure Sensor Included: No
