Holley Billet EFI Return Style Fuel Pressure Regulator
SKU
HTPD-12-893
List price
$256.80
Price
$191.95
Description
EFI Return Style Regulator 59.5 PSI Black Finish
Features
- Constructed from Billet 6061-T6 Aluminum
- Anodized in all black or black and clear
- Machined for all SAE6 ports, with 3 6AN fittings included
- Includes an extra plug to replace one fitting when installed post throttle body / fuel rail
- Can be disassembled and re-oriented to suit desired fuel routing
- Pre-set 59.5 psi
- Compatible with Holley Sniper and Sniper Stealth among other applications
- Regulator is suitable up to 110 GPH pump flowrate. In terms of pump models that would be a 525lph pump or smaller.
Specs
Brand
HOLLEY
Category
Fuel Pressure Regulator
Specs
Brand: Holley
Color: Black
Style: Return Style
Warning: California Proposition 65
Category: Air and Fuel Delivery
Material: Billet 6061 Aluminum
Warranty: Manufacturer's Limited 90 Day Warranty
Fuel Type: Gasoline
part type: Fuel Pressure Regulator
Adjustable: No
Gauge Port: No
Grade Type: Performance
Inlet Size: 6 AN
Inlet Type: 6 AN
Application: Universal
Fuel System: EFI
Outlet Size: 6 AN
Outlet Type: 6 AN
Return Size: 6 AN
Product Type: Fuel Pressure Regulator
Sub Category: Carburetion
Emission Code: 5
Mounting Type: Inline
Port Quantity: 3
Inlet Quantity: 1
Pressure Range: 59.5 Pre-Set
Outlet Quantity: 1
Mounting Hardware Included: No
