Connect with the Wild with the PROJECT X - Series X High Power LED auxiliary lights. The Series X LED lights feature best in class performance and is engineered using Osram LED technology to cut through the darkness and light the trail ahead with a powerful combo beam.

Featuring an integrated Active Thermal Management System (ATMS), the HP.70 delivers 120 watts of pure white light (5700-8K) in a broad penetrating beam of light.
Unparalleled Performance 5-Watt High Power Osram-LEDs producing 120W of pure white light (5700 degree K) and 15,000 raw lumens (8889 effective) per light

LED Front Position Light Pipe - Signature built-in LED light pipe meets ECE requirements for front position light improving daytime driving visibility and safety.
Customizable Appearance - Customize the look of your Series X HP.70s with your choice of 3 inner trim pieces, including Brocky Blue, Dragon Red and PROJECT X Green.

The light is fully sealed making the ring simple and easy to swap without compromising light performance or affecting warranty.

Power

• Input voltage: 9-33V
• LED Power: 120W
• Current Draw at 12V: 8.9A
• Operating Temp: -40 degree F to 149 degree F
• Heat Management: Active, Thermal Management, System (ATMS)
• Protection: Reverse Polarity Protection
• EMC: ECE R10

LED Type: Osram LEDs No. LEDs: 24

• 7 Inch Combo Beam

Lumens

• Color Temp: 5700 degree K
• Color Rendering Index: 72
• Raw Lumens: 15,000
• Effective Lumens: 8,889
• Beam Length (1 lamp): 1 lux at 1886 Feet
• Beam Length (2 lamps): 1 lux at 2664 Feet
• Beam Width (1 lamp): 1 lux at 147 Feet
• Beam Width (2 lamps): 1 lux at 206 Feet

Construction

• Housing: Pressure die-cast aluminum
• Lens: Hard coated Polycarbonate
• Hardware: Stainless Steel
• IP Rating: IP66 & IP67
• Weight: 3.85 lbs

Details:

• Beam Length (1 lamp): 1 lux at 1886 Feet
• Beam Length (2 lamps) : 1 lux at 2664 Feet
• Beam Width (1 lamp): 1 lux at 147 Feet
• Beam Width (2 lamps) : 1 lux at 206 Feet
• Brocky Blue, Dragon Red and PROJECT X Green Bulb Quantity: 24
• Bulb Technology: LED
• Bulb Type: Osram LEDs
• Color Rendering Index: 72
• Connector Gender: Male
• Connector Quantity: 1
• Material: Die Cast Aluminum
• Effective Lumens: 8889
• EMC: ECE R10
• Hardware Included: Yes
• Hardware Material: Stainless Steel
• Heat Management: Active Thermal
• Management System Height: 7.8 inch.
• Housing Color: Black
• Housing Finish: Flat
• Housing Material: Pressure die-cast aluminum
• Input Voltage Range: 9 - 33V DC
• IP Rating: IP67
• Lamp Current Draw at 12V: 8.77 Amps
• Lens Color: Clear
• Lens Material: Hard coated Polycarbonate
• Mounting Hole Quantity: 3
• Operating Temp: Neg 40 Degree F to 149 Degree F Positional Light Current Draw at 12V: 0.17 Amps
• Protection: Reverse Polarity Protection
• Terminal Gender: Female Terminal
• Quantity: 1 Terminal
• Type: Deutsch DT 3-pin
• Total Current Draw at 12V: 9 Amps Wattage Draw at 12V DC: Driving Light - 106 Watts, Position - 2.2 Watts
• Wire Quantity: 3
• Wiring Harness Included: Y
• Weight: 3.85 LBS
• Width: 4 inch.
